TRANS-TEC MACHINE EQUIPMENT LIST
TYPE Machine Info QT Travels Accessory Acc Feature Tools Spec Features Image
CNC LATHE
CNC LATHE IKEGAI TU 30 1 X=25” Z=60” 15” CHUCK 3.5” HOLE THRU SPINDLE 12 Tool Turret   TU 30
CNC LATHE DAEWOO PUMA 6S 1 X=14.1” Z=16.6” 6” CHUCK 1.5” HOLE THRU SPINDLE 12 TOOL TURRET COLLETS Puma 6S
CNC LATHE MORI-SEIKI SL35B 1 X=18” Z=35” 12” CHUCK 3.625” HOLE THRU SPINDLE 10 TOOL TURRET   SL 35
CNC LATHE MORI-SEIKI SL25B 2 X=20.5” Z=24.6” 10” CHUCK 2.625” HOLE THRU SPINDLE 10 TOOL TURRET COLLETS, PARTS CATCHER SL 25B
CNC LATHE HWACHEON MEGA-100 1 X=38” Z=120” 28” CHUCK 10.2” HOLE THRU SPINDLE 10 TOOL TURRET   MEGA 100
CNC LATHE HWACHEON HI-ECO 45 1 X=37” Z=78.7” 21” CHUCK 4.6” HOLE THRU SPINDLE 12 TOOL TURRET   Echo 45
CNC LATHE MORI-SEIKI SL-3 1 X=12.6” Z=22” 10” CHUCK 4” HOLE THRU SPINDLE 8 TOOL TURRET   SL 35
CNC LATHE LIVE TOOLS HARDINGE CONQUEST T-42C 1 X=6.37” Z=16” Y=6” 6” CHUCK 1.89”HOLE THRU SPINDLE 16 TOOL TURRET LIVE TOOLING,SUB SPINDLE,BAR FEEDER Hardinge T42
CNC LATHE MORI SEIKI TL-3 1 X=18” Z=22.5” 10” CHUCK 4” HOLE THRU SPINDLE 8 Tool Turret   TL 3
CNC MILL
CNC MILL DAH-LIH MCV-2100 1 X=83” Y=33” Z=30” KITAGAWA 16” 4TH AXIS CHUCK 6” HOLE THRU CHUCK 30 TOOL CHANGER   Dah Lih
CNC MILL KASUGA MRK-55 1 X=40” Y=20” Z=18” NIKKEN 10” 4TH AXIS 4” HOLE THRU CHUCK 21 TOOL CHANGER   KASUGA MRK 55
CNC MILL FADAL VMC 4020HT 3 X=40” Y=20” Z=20” FADAL 8” 4TH AXIS 1.75”HOLE THRU CHUCK 21 TOOL CHANGER   Fadal 4020
CNC MILL FADAL VMC 3016 HT 1 X=30” Y=16” Z=20” FADAL 8” 4TH AXIS 1.75”HOLE THRU CHUCK 21 TOOL CHANGER   Fadal 3016
CNC MILL SUPERMAX MAX 8 REBEL 1 X=65” Y=30” Z=30” KITAGAWA 15” 4TH AXIS 4” HOLE THRU CHUCK 30 TOOL CHANGER   SuperMax8
CNC MILL DOOSAN MV-3016LD 2 X=30” Y=16” Z=20” KITAGAWA 8” 4TH AXIS 1.75”HOLE THRU CHUCK 20 TOOL CHANGER CHIP BLASTER HP COOLANT DOOSAN MV 3016LD
CNC MILL DOOSAN DNM-400 1 X=30” Y=17” Z=20” KITAGAWA 8” 4TH AXIS 1.75”HOLE THRU CHUCK 30 TOOL CHANGER CHIP BLASTER HP COOLANT DNM 400
CNC MILL MORI-SEIKI MV-55 1 X=41” Y=21” Z=21” TSUDAKOMA 12” 4TH AXIS 4” HOLE THRU CHUCK 24 TOOL CHANGER   MV 55
CNC MILL MORI-SEKI MDL MV-65 1 X=60” Y=30” Z=30” NIKKEN 12” 4TH AXIS 4” HOLE THRU CHUCK 30 TOOL CHANGER   MV 65
CNC MILL KURAKI HMC-400 1 X=23” Y=11” Z=11” 15” TWIN PALLET SHUTTLE 800 LB CAPACITY 20 TOOL CHANGER   KURAKI
CNC MILL MORI-SEIKI SH-63 HBM 1 X=33” Y=30” Z=33” 25”TWIN PALLET SHUTTLE 2,600 LB CAPACITY 60 TOOL CHANGER HP COOLANT MORI SEIKI SH 63 HBM
CNC MILL DOOSAN DHC-400 DS HBM 1 X=23” Y=22” Z=22” 15” TWIN PALLET SHUTTLE 881 LB CAPACITY 40 TOOL CHANGER CHIP BLASTER HP COOLANT DOOSAN DHC 400 DS HBM
EDM
EDM CHARMILLES ROBOFIL 310 1 X=15.7” Y=9.8” Z=15.75” 30 DEG TAPER ANGLE X=33.5” Y=19.7” Z=15.75” .004”-.012” WIRE 4 AXIS X,Y,U,V Robofil 310
EDM CHARMILLES ROBOFIL 290 1 X=15.7” Y=9.8” Z=7.8” 30 DEG TAPER ANGLE X=33.5” Y=19.7” Z=15.75” .004”-.012” WIRE 4 AXIS X,Y,U,V Robofil 290
EDM CHARMILLES ROBOFIL 330F 2 X=15.7” Y=11.8” Z=15.7” 30 DEG TAPER ANGLE X=29” Y=21” Z=15.75” .004”-.012” WIRE 4 AXIS X,Y,U,V SUBMERSIBLE CHARMILLES ROBOFIL 330F
EDM CHARMILLES ROBOFORM 550 1 X=23.6” Y=15.7” Z=17.7” “C” AXIS TABLE 29.5” X 23.75” LINEAR TOOL CHANGER   CHARMILLES ROBOFORM 550
EDM CHARMILLES ROBOFORM 50 1 X=23.6” Y=15.7” Z=17.7” “C” AXIS TANK 48” X=34” Y=18” 6 TOOL CHANGER   Roboform 50
EDM CHARMILLES ROBOFORM 22 1 X=11.8” Y=9.8” Z=9.8” 5TH ROTARY AXIS TANK 37” X=20.9” Y=13” “C” AXIS 4 TOOL CHANGER   Roboform 22
EDM CHARMILLES ROBOFORM 23 1 X=13.78” Y=9.8” Z=9.8” 5TH ROTARY AXIS TANK 31.5” X=21.6” Y=14” “C” AXIS 4 TOOL CHANGER   Roboform 22
EDM GENSPARK AMERICA CY1050 1     TANK 55” X=39” Y-20” 3R TOOLING SYSTEM   GENSPARK AMERICA CY1050
EDM CHARMILLES HD 30 CNC 1 X=11.8” Y=7.87” Z=11.81” W=3.93” TABLE  15.74” X 11.81” TANK 28.7” X 18.5” MANUAL “W” AXIS HOLE POPPER CHARMILLES HD 30 CNC
EDM CHEVALIER ED-252 1 X=11.8” Y=7.9” Z=7.9” DIGITAL READOUT TANK 29” X=19” Y=9” 3R TOOLING SYSTEM   Chevalier ED 252
EDM EASCO PHOENIX 130 1 X=12” Y=6” Z=8” DIGITAL READOUT TANK 27” X=14” Y=13” 3R TOOLING SYSTEM   EASCO PHOENIX 130
EDM JAPAX SDX30NC 1 X=12” Y=8” Z=8”   WORK AREA X=11.81” Y=9.84” .008”-.187” DIA EDM DRILL Japax
EDM UNITEK 1 X=19” Y=26” Z=21”   WORK AREA X=11.81” Y=9.84”   DISINTEGRATOR unitek
LASERS
LASER WELDER ALFA-LASER ALM 200 1 X=4.7” Y=4.7” Z=19.6”-59” BELOW ELBOW STERO MICROSCOPE 14X RADIAL SWING BELOW ELBOW=55” RADIUS MOTORIZED JOYSTICK X-Y-Z POSITION CONTROL DEEP PENETRATING LASER PLASMA WELDER ALFA LASER ALM 200
LASER PART MARKER JIMANI FLFB60 LASER MARKING SYSTEM 1 4.7S” SQUARE TO 12” SQUARE Z=19” 1.5X REVERSIBLE BEAM EXPANDER ROTARY 4TH AXIS FOOTSWITCH FOR HANDS FREE OPERATION PROLASE 10 LASER MARKING SOFTWARE JIMANI FLFB60 LASER MARKING SYSTEM
MANUAL MILL
MANUAL MILL SEIKI 1 X=30” Y=16” Z=5” DIGITAL READOUT VERTICAL KNEE 16” R8 COLLET   SEIKI MAN MILL
MANUAL MILL BRIDGEPORT SERIES II 1 X=33” Y=15” Z=5” DIGITAL READOUT VERTICAL KNEE 16” R8 COLLET W/8” RISER BLOCK BRIDGEPORT SERIES II MAN MILL
MANUAL MILL BRIDGEPORT 1 X=30”  Y=9”  Z=5” DIGITAL READOUT VERTICAL  KNEE 16” R8 COLLET   BRIDGEPORT MAN MILL
MANUAL MILL REPUBLIC LAGUN 1 X=30” Y=9” Z=5” DIGITAL READOUT VERTICAL KNEE 16” R8 COLLET   Republic
MANUAL MILL SHARP 2 X=50” Y=10” Z=6” DIGITAL READOUT 22” POWERED SPINDLE NOSE T 40 TAPER TOOL HOLDER ACU-RITE PROGRAMMABLE CONTROL SHARP MAN MILL
MANUAL LATHE
MANUAL LATHE MAZAK 30-120 1 30” X 120” DIGITAL READOUT 4” HOLE THRU CHUCK   TAPER ATTATCHMENT 40” GAP BED MAZAK 30 120 MAN LATHE
MANUAL LATHE SHARP 2680C 2 26” X 80” DIGITAL READOUT 4.5” HOLE THRU CHUCK   TAPER ATTATCHMENTS SHARP 2680C MAN LATHE
MANUAL LATHE HWACHEON LATHE 1 21” X 60” DIGITAL READOUT 3” HOLE THRU CHUCK   TAPER ATTATCHMENTS 29.5” GAP BED HWACHEON LATHE MAN LATHE
MANUAL LATHE LEBLONDE LATHE 1 19” X 78” DIGITAL READOUT 3” HOLE THRU CHUCK   TAPER ATTATCHMENTS Leblond
MANUAL LATHE HARDINGE PRECISION HL V2 2 8.5” X 36” DIGITAL READOUT 1” HOLE THRU CHUCK   TAPER ATTATCHMENTS HARDINGE PRECISION HL V2 MAN LATHE
MANUAL LATHE HARDINGE PRECISION DSM 1 8.5” X 16”   1” HOLE THRU CHUCK     HARDINGE PRECISION DSM MAN LATHE
